Professional Automatic Swing Gate Installation Services - DC24V Heavy-Duty Motor System & Smart Remote Control for Modern Residential & Industrial Properties
Classification :
PRODUCT DETAILS
Get expert automatic swing gate installation services featuring a high-performance DC24V custom motor system. Combining precision engineering, heavy-duty mechanical strength, and advanced obstacle detection, it delivers reliable operation, impact resistance, and maximum entry security for residential and industrial properties worldwide.
Specifications
| System Application | Hotels, Luxury Villas, Real Estate Complexes, Elite Residences |
| Model Number | Ba-L2 |
| Brand Name | Baroxon Autogate |
| Warranty Period | 1 Year |
| Motor Voltage | 12V/24V |
| Max Leaf Load | 200KGS |
| Opening Speed | 1.6CM/S |
| Protection Class | IP45 (Weatherproof) |
| Operating Temperature | -20°C~+70°C |
| Chassis Material | Aluminum Alloy |
| Component Model | Ba-L2-12V |
| Power Supply | AC110/220 |
| Motor Working Voltage | 12V |
| Absorbed Power | 28W |
| Max Leaf Length | 2.5M |
| Max Leaf Load | 200KGS |
| Thrust | 400N |
| Duty Cycle | 95% |
| Open Angle | 0~120° |
| System Application | Condominiums, Luxury Villas, Commercial Properties, Gated Estates |
| Model Number | Ba-L2 |
| Brand Name | Baroxon Autogate |
| Warranty Period | 1 Year |
| Motor Voltage | 12V/24V |
| Max Leaf Load | 200KGS |
| Opening Speed | 1.6CM/S |
| Protection Class | IP45 (Weatherproof) |
| Operating Temperature | -20°C~+70°C |
| Chassis Material | Aluminum Alloy |
| Component Model | Ba-L2-12V |
| Power Supply | AC110/220 |
| Motor Working Voltage | 12V |
| Absorbed Power | 28W |
| Max Leaf Length | 2.5M |
| Max Leaf Load | 200KGS |
| Thrust | 400N |
| Duty Cycle | 95% |
| Open Angle | 0~120° |
Product Images
Key Advantages
Up to 800 kg Load
Automates sliding gates up to 800 kg and swing gates up to 250 kg per leaf: for homes, communities and commercial sites.
Powerful Motor
A reliable AC or 24V DC motor with an all-metal gearbox provides smooth and powerful gate movement.
Safety Sensors
Infrared sensors and current monitoring stop the gate at obstacles, protecting people, vehicles and the drive unit.
Backup Power & Solar Panels
24V models support backup batteries and solar panels for uninterrupted operation during power outages.
Quiet Smooth Start & Stop
Gradual acceleration and braking reduce wear, extend service life and keep operation quiet.
Frequently Asked Questions (FAQs)
Which gates is this operator suitable for?
The kit automates sliding gates up to 800 kg (and swing gates up to 250 kg per leaf on dual-leaf models) for private homes, communities and commercial sites.
What power supply is required?
220V AC and 24V DC models are available. 24V versions support backup batteries and solar panels for uninterrupted operation during power outages.
How are vehicles and people protected?
Infrared safety sensors and current monitoring stop the gate when an obstacle is detected; smooth start and stop protect the drive and extend service life.
Will the gate work during a power outage?
Yes, on 24V models with a backup battery the operator continues to work; in any case the gate can be opened mechanically with the manual release keys.
How fast do the gates open?
Opening speed is 20 cm/s; for sliding gates it is smooth and safe, with an adjustable pause before automatic closing.
What warranty and service are provided?
The warranty is 12 months; online technical support and spare parts are available for the entire service life of the operator.
