Digital Ticket Validation Automatic Tripod Turnstile Gate with Biometric Face Recognition for Stadiums and Arenas – Professional Access Control System
Classification :
PRODUCT DETAILS
Secure stadiums and arenas and streamline spectator admissions with our digital ticket validation automatic tripod turnstile gate. Featuring integrated barcode ticket scanning and biometric face recognition, it combines rapid-response rotating arms, high-frequency durability, and anti-tailgating mechanisms, delivering reliable crowd management worldwide
Specifications
| IP Rating Protection | IP54 |
| Barrier Open/Close Speed | 0.2 s. 0.4 s. 0.5 s |
| Barrier Motor Unit | Brushless Motor (High Speed) |
| Access Control Type | RFID Card. QR Code. Fingerprint. Face Recognition. ESD System |
| Turnstile Function | Anti-Pinch. Collision Avoidance. Anti-Tailgating |
| Operational Direction | 2-Way (Bidirectional) |
| Communication Interface | RS485 / TCP/IP Support |
| Casing Material | 304 Stainless Steel (Anti-Rust) |
| Brand Name | Baroxon |
| Model Series | Ba-601 |
| Product Designation | Tripod Turnstile Auto with Hydraulic System |
| Physical Dimensions | 1200 * 280 * 980 mm ( L* W* H) |
| Lane Width Passage | 550-600mm |
| Throughput Passage Speed | 30persons/min (IC.ID card) |
| Environment Suitability | Indoor Outdoor (Weatherproof) |
| Power Supply Voltage | AC 110 .220 V. 50 / 60 Hz |
| MCBF Metric | 5 Million Cycles |
| LED Visual Indicator | Yes (High Visibility) |
| Structural Parameter | Engineering Specification |
| Turnstile System Type | Hydraulic Auto Tripod Turnstile |
| Main Cabinet Material | 304 Stainless Steel (Hairline Finish) |
| Barrier Arm Material | High-Strength 304 Stainless Steel |
| Lane Flow Configuration | Single / Bidirectional |
| Operating Temperature Range | -25°C to +70°C (Optimized for Tropical Humidity) |
| Third-Party Integration | Supports RFID, QR Scan, and Face Recognition |
| Logistics Packaging Method | Foam + Strong Carton + Waterproof Wooden Crate |
| Net Unit Weight | 68.000 kg |
| Package Dimensions | 10X10X98 cm |
Product Images
Key Advantages
Multiple Credential Options
RFID cards and key fobs, PIN, QR, fingerprint and face recognition — configure the right combination for each entrance.
High Throughput
From 30 people per minute on tripods to 60 on optical speed gates — no queues even during peak hours.
Anti-Tailgating Control
Optical sensors and mechanical blocking prevent unauthorized passage behind an authorized user.
Premium Stainless Steel 304
Durable brushed stainless steel housing with a modern design that fits any interior.
Integration with Existing Systems
Wiegand, RS485 and TCP/IP interfaces connect the equipment to most СКУД platforms, attendance and visitor systems.
Frequently Asked Questions (FAQs)
Which credentials does the system support?
RFID cards and key fobs, PIN codes, QR tickets, biometric fingerprint and face recognition — a combination can be configured for each entrance.
What is the throughput of the turnstiles?
Tripod turnstiles pass up to 30 people per minute, swing barriers up to 40, and optical speed gates up to 60 — enough for offices and public facilities during peak hours.
How is anti-tailgating protection implemented?
Swing barriers and speed gates use optical sensors that detect attempts to pass without authorization; in tripod turnstiles, the mechanism physically blocks passage.
Can the equipment be installed outdoors?
Yes, models with protection class {ip} are designed for outdoor installation — entrances of stadiums, transport facilities and residential territories.
Does the system integrate with an existing access control system?
Yes. The equipment supports Wiegand, RS485 and TCP/IP and connects to most СКУД platforms, attendance systems and visitor management software.
What warranty and service are provided?
Standard warranty is 12 months; online technical support, spare parts supply and remote diagnostics are available for the entire service life.
Videos & Demonstrations
FAQ
What is the delivery time?
Standard production and shipping time is 15 to 30 days depending on model and order volume.
Is there a warranty?
Yes, all products carry a factory warranty, plus technical support and after-sales service.
Can I order OEM/ODM?
Yes, we manufacture to your requirements: color, logo, boom arm length, configuration and integration.
How do I get a quote?
Submit the form, message us on WhatsApp or e-mail and we will respond within one working hour.
