Premium 304 Stainless Steel Automatic Flap Barrier Turnstile Gate with Integrated RFID and Biometric Fingerprint Access Control System – Modern Corporate Office Security Solution
Classification :
PRODUCT DETAILS
Secure modern corporate offices and streamline employee entry with our premium 304 stainless steel automatic flap barrier turnstile gate. Featuring integrated RFID card reading and biometric fingerprint recognition, it combines rapid-response retractable wings, precision optical sensors, and high-frequency durability, delivering seamless traffic flow and maximum protection worldwide.
Specifications
| Place of Origin | Shandong, China (Premium Enterprise Grade) |
| Model Number | Ba-Y310 (High Speed Access Series) |
| Brand Name | Baroxon |
| Product Name | Flap Barrier Gate (Automated Optical Turnstile) |
| Material | SUS304 Stainless Steel (Corrosion Resistant) |
| Power Supply | AC 220V/110V ±10% 50/60Hz (Standard Power Input) |
| Working Environment | Temperature: -10℃ ~ +60℃ (Indoor & Sheltered Outdoor) |
| Thickness of Steel | 1.5mm Heavy Duty Panel |
| Pass Speed | 30-40 Persons/min (Anti-Tailgating Flow) |
| Passage Width | 550-600mm Standard Lane |
| Passage Direction | Bi-directional (Dual-Way Control) |
| Warranty | Lifetime Technical Assistance & Support |
| Application | Security Access Control Management (Commercial Building Security Infrastructure) |
| Packaging Details | Foam, carton box, export-grade wooden crate (Secure for Sea Freight & Port Delivery) |
| Port of Dispatch | Shenzhen, China |
| Selling Units | Single Unit |
| Single Package Size | 147X38X117 cm |
| Single Gross Weight | 80.000 kg |
| Supply Ability | 2000 units per Month |
| Housing Material | SUS304 Grade Stainless Steel (Industrial Specification) |
| Arm Material | Acrylic / Soft Arm (Anti-Collision Mechanism) |
| Size | 1200*300*980mm |
| Lane width | 600mm |
| Arm Length | 260mm |
| Passing speed | 35--50 people/min |
| Open/close speed | 0.2sec (Rapid Response Activation) |
| MCBF (Lifespan) | 5.000.000 cycles (High Durability Engine) |
| Driving Motor | Brushed Motor (Optimized Torque) |
| Input Signal | Dry Contact (Seamless Biometric & Facial Integration) |
Product Images
Key Advantages
Multiple Credential Options
RFID cards and key fobs, PIN, QR, fingerprint and face recognition — configure the right combination for each entrance.
High Throughput
From 30 people per minute on tripods to 60 on optical speed gates — no queues even during peak hours.
Anti-Tailgating Control
Optical sensors and mechanical blocking prevent unauthorized passage behind an authorized user.
Premium Stainless Steel 304
Durable brushed stainless steel housing with a modern design that fits any interior.
Integration with Existing Systems
Wiegand, RS485 and TCP/IP interfaces connect the equipment to most СКУД platforms, attendance and visitor systems.
Frequently Asked Questions (FAQs)
Which credentials does the system support?
RFID cards and key fobs, PIN codes, QR tickets, biometric fingerprint and face recognition — a combination can be configured for each entrance.
What is the throughput of the turnstiles?
Tripod turnstiles pass up to 30 people per minute, swing barriers up to 40, and optical speed gates up to 60 — enough for offices and public facilities during peak hours.
How is anti-tailgating protection implemented?
Swing barriers and speed gates use optical sensors that detect attempts to pass without authorization; in tripod turnstiles, the mechanism physically blocks passage.
Can the equipment be installed outdoors?
Yes, models with protection class {ip} are designed for outdoor installation — entrances of stadiums, transport facilities and residential territories.
Does the system integrate with an existing access control system?
Yes. The equipment supports Wiegand, RS485 and TCP/IP and connects to most СКУД platforms, attendance systems and visitor management software.
What warranty and service are provided?
Standard warranty is 12 months; online technical support, spare parts supply and remote diagnostics are available for the entire service life.
Videos & Demonstrations
FAQ
What is the delivery time?
Standard production and shipping time is 15 to 30 days depending on model and order volume.
Is there a warranty?
Yes, all products carry a factory warranty, plus technical support and after-sales service.
Can I order OEM/ODM?
Yes, we manufacture to your requirements: color, logo, boom arm length, configuration and integration.
How do I get a quote?
Submit the form, message us on WhatsApp or e-mail and we will respond within one working hour.
