Anti-Smash Vehicle Detection Radar Sensor for Automatic Boom Barriers – Anti-Collision Safety Detector for Metal and Plastic Parking Gates
Classification :
PRODUCT DETAILS
Prevent gate strikes and protect vehicles with our anti-smash vehicle detection radar sensor. Designed for automatic boom barriers, it combines high-precision microwave detection, rapid anti-collision response, and universal compatibility with metal and plastic parking gates, delivering reliable traffic management and maximum vehicle safety worldwide.
Specifications
| Chassis Material | Plastic |
| Reflective Level | Engineer Grade |
| Brand Name | Baroxon |
| Model Number | Ba-79G-PRO |
| Official Product Name | Radar Vehicle Detector |
| Refresh Rate | 13.3Hz |
| Response Time | 75ms |
| Product Weight | 183g |
| Working Frequency | 77GHz-81GHz |
| Detection Distance Range | 0.5m~0.7m |
| Detection Level Range | -1~1m |
| Adjustment Mode | Bluetooth / Serial |
| Package Dimensions | 112.75mm*111.75mm*47.81mm |
| Horizontal Angle | 120° |
| Frequency Range | 77GHz - 81GHz (High Precision) |
| Horizontal Detection Angle | 120° Wide Coverage |
| Vertical Detection Angle | ±15° Adjustable |
| Communication Interface | Bluetooth, Serial Port, Relay Node |
| Operating Temperature | -40°C to +85°C (Optimized for extreme tropical and high humidity climates) |
| Waterproof Certification | IP67 High Level Protection |
| Sales Unit | Single item per box (Wholesale) |
| Package Box Dimensions | 12 x 12 x 5 cm |
| Gross Weight | 0.183 kg |
| Supply Availability | Ready Stock for immediate international shipping and project fulfillment |
Product Images
Key Advantages
Millimeter-Wave Precision
The 79 GHz radar detects vehicles and obstacles with high accuracy and angular resolution at ranges up to 6 m.
Induction Loop Replacement
No road cutting required: the sensor mounts above the lane and contactlessly detects vehicles, pedestrians and obstacles.
Boom Impact Protection
Real-time monitoring of the area under the arm prevents the barrier from lowering onto a vehicle or pedestrian.
All-Weather Sealed Housing
The sealed enclosure with IP65 protection (weather-resistant for the Singapore climate) works in rain, snow, fog, dust and temperature changes.
Wireless Configuration
Bluetooth app setup: detection zone, sensitivity and delay are configured without opening the housing.
Frequently Asked Questions (FAQs)
At what distance does the radar detect vehicles?
The 79 GHz millimeter-wave radar reliably detects vehicles at ranges up to 6 m with high angular resolution, fully covering the approach zone to the barrier.
Does the sensor replace induction loops?
Yes. The radar replaces loop detectors and infrared photocells: it detects vehicles, pedestrians and obstacles without cutting the road surface, simplifying installation and maintenance.
How does boom impact protection work?
The sensor monitors the area under the arm in real time: if a vehicle or pedestrian appears, the barrier stops lowering and raises the arm to prevent a collision.
Does the sensor work in rain, snow and frost?
Yes. The housing is rated IP65 (weather-resistant for the Singapore climate), and the millimeter-wave radar is unaffected by precipitation, fog, dust and temperature changes.
How is the sensor configured?
Configuration is done over Bluetooth from a smartphone app: detection zone, sensitivity and trigger delay are set without opening the housing.
Which barriers and gates is the sensor compatible with?
The sensor has standard relay outputs and works with BAROXON barriers as well as most universal barrier and gate operators.
Videos & Demonstrations
FAQ
What is the delivery time?
Standard production and shipping time is 15 to 30 days depending on model and order volume.
Is there a warranty?
Yes, all products carry a factory warranty, plus technical support and after-sales service.
Can I order OEM/ODM?
Yes, we manufacture to your requirements: color, logo, boom arm length, configuration and integration.
How do I get a quote?
Submit the form, message us on WhatsApp or e-mail and we will respond within one working hour.
